Picture of Iscar HM390 FTD D4.00-6-1.5-15 Milling Cutter 90.0° 4.000 Diameter Face Mill 1.500 2.000 OAL 6 Flute

Iscar HM390 FTD D4.00-6-1.5-15 Milling Cutter 90.0° 4.000 Diameter Face Mill 1.500 2.000 OAL 6 Flute

Part Number: ISC3106565 ISO: HM390 FTD D4.00-6-1.5-15 ANSI:HM390 FTD D4.00-6-1.5-15

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: 1012487
Vendor: Sussex Tool and Supply
$1,000.00
ISCAR 3106565 Triangle 90.0°, Face Mill SHELL1.5000 Positive 4.0000 101.60MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
Shipping State TEXAS
Made In USA NO
Cutter Type Face Mill
Tool Material Steel
Machine Side Connection Type Face Mill/Shell Mill
Mach Side Connection Size 1.5000 38.10MM
Overall Length 2.0000 50.80MM
Coolant Thru Thru Coolant
Flutes/Inserts 6
Tool Dia 4.0000 101.60MM
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Insert Application Roughing, Semi Finishing
Insert Style TD
Insert Shape/Cutter Pocket Shape Triangle
Insert Type Positive
Insert Size Ic 15
Cut Dia Min 4.0000 101.60MM
Coolant Type Through Hole
Depth Of Cut Max 0.5120
Cut Dia Max 4.0000 101.60MM
Insert Screw 7005206
Cutting Edge Angle 90.0°
