Picture of Iscar H490 E90AX D.62-2-W.62-09 Milling Cutter 90.0° 0.625 Diameter Weldon 0.625 3.250 OAL 2 Flute

Iscar H490 E90AX D.62-2-W.62-09 Milling Cutter 90.0° 0.625 Diameter Weldon 0.625 3.250 OAL 2 Flute

Part Number: ISC3105270 ISO: H490 E90AX D.62-2-W.62-09 ANSI:H490 E90AX D.62-2-W.62-09
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012268
Vendor: Sussex Tool and Supply
$356.16

Description

ISCAR 3105270 Parallelogram 90.0°, End Mill End Mill Weldon 0.6250 Negative 0.6250 15.88MM - 5/8Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type End Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style AN
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Negative
Coolant Type Through Hole
Insert Screw 7005890
Dimensions & Sizing
Overall Length 3.2500 82.55MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Flutes/Inserts 2
Tool Dia 0.6250 15.88MM - 5/8
Insert Size Ic 9
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 0.6250 15.88MM - 5/8
Depth Of Cut Max 0.3150
Cut Dia Max 0.6250 15.88MM - 5/8
Materials & Finish
Tool Material Steel
