Picture of Iscar FF EW D1.50-5.0-CF4-06-C Milling Cutter 1.500 Diameter Clickfit 1.574 7.130 OAL 4 Flute

Iscar FF EW D1.50-5.0-CF4-06-C Milling Cutter 1.500 Diameter Clickfit 1.574 7.130 OAL 4 Flute

Part Number: ISC3103618 ISO: FF EW D1.50-5.0-CF4-06-C ANSI:FF EW D1.50-5.0-CF4-06-C
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012074
Vendor: Sussex Tool and Supply
$648.00

Description

ISCAR 3103618 Trigon Feed Mill Quick Change CF4 Positive 1.5000 38.10MM - 1-1/2Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Indexable Feed Mill
Coolant Thru Thru Coolant
Type Of Tool Quick Change
Insert/Tool TOOL
Cut Type General Purpose
Insert Style FF
Insert Shape/Cutter Pocket Shape TRIGON
Insert Type Positive
Coolant Type Through Hole
Insert Screw 7003603
Dimensions & Sizing
Overall Length 7.1300 181.10MM
Shank/Pilot Dia 1.5748 40.00MM
Flutes/Inserts 4
Tool Dia 1.5000 38.10MM - 1-1/2
Insert Size Ic 6
Performance & Capacity
Cut Dia Min 0.9500 24.13MM
Depth Of Cut Max 0.3030
Cut Dia Max 1.5000 38.10MM - 1-1/2
Max Ramp Angle 2.50°
Materials & Finish
Tool Material Steel
