Picture of Iscar FF EW D1.5-6.0-W1.25-09-C Milling Cutter 1.500 Diameter Weldon 1.250 8.580 OAL 3 Flute

Iscar FF EW D1.5-6.0-W1.25-09-C Milling Cutter 1.500 Diameter Weldon 1.250 8.580 OAL 3 Flute

Part Number: ISC3103414 ISO: FF EW D1.5-6.0-W1.25-09-C ANSI:FF EW D1.5-6.0-W1.25-09-C
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012033
Vendor: Sussex Tool and Supply
$560.64

Description

ISCAR 3103414 Trigon Feed Mill End Mill Weldon 1.2500 Positive 1.5000 38.10MM - 1-1/2Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Indexable Feed Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style FF
Insert Shape/Cutter Pocket Shape TRIGON
Insert Type Positive
Coolant Type Through Hole
Insert Screw 7002377
Dimensions & Sizing
Overall Length 8.5800 217.93MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 3
Tool Dia 1.5000 38.10MM - 1-1/2
Insert Size Ic 9
Performance & Capacity
Cut Dia Min 0.6800 17.27MM
Depth Of Cut Max 0.0800
Cut Dia Max 1.5000 38.10MM - 1-1/2
Max Ramp Angle 5.00°
Materials & Finish
Tool Material Steel
