Picture of Iscar FF EW D1.00-3.0-W1.0-06-C Milling Cutter 0.450 Diameter Weldon 1.000 5.770 OAL 2 Flute

Iscar FF EW D1.00-3.0-W1.0-06-C Milling Cutter 0.450 Diameter Weldon 1.000 5.770 OAL 2 Flute

Part Number: ISC3103257 ISO: FF EW D1.00-3.0-W1.0-06-C ANSI:FF EW D1.00-3.0-W1.0-06-C
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012025
Vendor: Sussex Tool and Supply
$447.36

Description

ISCAR 3103257 Trigon Feed Mill End Mill Weldon 1.0000 Positive 0.4500 11.43MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Indexable Feed Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style FF
Insert Shape/Cutter Pocket Shape TRIGON
Insert Type Positive
Coolant Type Through Hole
Insert Screw 7000229
Dimensions & Sizing
Overall Length 5.7700 146.56MM
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 2
Tool Dia 0.4500 11.43MM
Insert Size Ic 6
Performance & Capacity
Cut Dia Min 0.4500 11.43MM
Depth Of Cut Max 0.2200
Cut Dia Max 1.0000 25.40MM
Max Ramp Angle 5.00°
Materials & Finish
Tool Material Steel
