Picture of Iscar FF EW D1.00-2.0-W1.0-06-C Milling Cutter 1.000 Diameter Weldon 1.000 4.760 OAL 2 Flute

Iscar FF EW D1.00-2.0-W1.0-06-C Milling Cutter 1.000 Diameter Weldon 1.000 4.760 OAL 2 Flute

Part Number: ISC3103413 ISO: FF EW D1.00-2.0-W1.0-06-C ANSI:FF EW D1.00-2.0-W1.0-06-C
Tool Cross-Reference
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012032
Vendor: Sussex Tool and Supply
$431.04

Description

ISCAR 3103413 Trigon Feed Mill End Mill Weldon 1.0000 Positive 1.0000 25.40MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Indexable Feed Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style FF
Insert Shape/Cutter Pocket Shape TRIGON
Insert Type Positive
Coolant Type Through Hole
Insert Screw 7002377
Dimensions & Sizing
Overall Length 4.7600 120.90MM
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 2
Tool Dia 1.0000 25.40MM
Insert Size Ic 6
Performance & Capacity
Cut Dia Min 0.4500 11.43MM
Depth Of Cut Max 0.0800
Cut Dia Max 1.0000 25.40MM
Max Ramp Angle 5.00°
Materials & Finish
Tool Material Steel
