Picture of Iscar E45X D .31-W .62-06 Milling Cutter 45.0° 0.312 Diameter Weldon 0.625 3.250 OAL 1 Flute

Iscar E45X D .31-W .62-06 Milling Cutter 45.0° 0.312 Diameter Weldon 0.625 3.250 OAL 1 Flute

Part Number: ISC3100504 ISO: E45X D .31-W .62-06 ANSI:E45X D .31-W .62-06
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1011763
Vendor: Sussex Tool and Supply
$244.80

Description

ISCAR 3100504 Square 45.0°, Chamfer Mill End Mill Weldon 0.6250 Positive 0.3120 7.92MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Chamfer Mill
Coolant Thru Non Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style SO
Insert Shape/Cutter Pocket Shape Square
Insert Type Positive
Coolant Type External
Insert Screw 7000402
Dimensions & Sizing
Overall Length 3.2500 82.55MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Flutes/Inserts 1
Tool Dia 0.3120 7.92MM
Insert Size Ic 6
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 0.3120 7.92MM
Depth Of Cut Max 2.0000
Cut Dia Max 0.6300 16.00MM
Materials & Finish
Tool Material Steel
