Picture of Iscar CH45-.75-3.2-3-C.75-PN06 Milling Cutter 45.0° 0.734 Diameter Round 0.750 5.250 OAL 3 Flute

Iscar CH45-.75-3.2-3-C.75-PN06 Milling Cutter 45.0° 0.734 Diameter Round 0.750 5.250 OAL 3 Flute

Part Number: ISC3316312 ISO: CH45-.75-3.2-3-C.75-PN06 ANSI:CH45-.75-3.2-3-C.75-PN06
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1012822
Vendor: Sussex Tool and Supply
$309.12

Description

ISCAR 3316312 Pentagonal 45.0°, Chamfer Mill, Back Chamfer End Mill Cylindrical 0.7500 Positive 0.7340 18.64MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State TEXAS
Made In USA NO
Cutter Type Chamfer Mill, Back Chamfer
Coolant Thru Non Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type General Purpose
Insert Style PN
Insert Shape/Cutter Pocket Shape Pentagonal
Insert Type Positive
Coolant Type External
Insert Screw 7006639
Dimensions & Sizing
Overall Length 5.2500 133.35MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 3
Tool Dia 0.7340 18.64MM
Insert Size Ic 6
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 0.5280 13.41MM
Depth Of Cut Max 0.0590
Cut Dia Max 0.7340 18.64MM
Materials & Finish
Tool Material Steel
