Ingersoll XLB31750R71 IN2005 0.4921 (12.50 mm) Stainless/High TEMP

Part Number: ING6214984 ISO: XLB31750R71 IN2005

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: 1107016
$0.00
This product has a minimum quantity of 2
INGERSOLL 6214984 0.4921 (12.50 mm) STAINLESS/HIGH TEMP Carbide Titanium aluminium nitride (TiAlN) or aluminium titanium nitride (AlTiN; for aluminium contents higher than 50%) is a group of metastable hard coatings consisting of nitrogen and the metallic elements aluminium and titanium. This compound as well as similar compounds(such as TiN and TiCN) are most notably used for coating machine tools such and endmills and drills to change their properties, such as increased thermal stability and/or wear resistance. Four important compositions (metal content 100 wt.%) are deposited in industrial scale by physical vapor deposition methods:
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Insert
Tool Material Carbide
Cutting Edge Mat Carbide
Cut Rating Stainless Steel, High Temp
Coating TiAlN
Coolant Thru Thru Coolant
Flutes/Inserts 2
Tool Dia 0.4921 12.50MM
Type Of Tool Drill
Included Angle 140°
Cut Dia Min 0.4921 12.50MM
Dia Deep 1.5.0x Dia, 5.0x Dia, 3.0x Dia, 8.0x Dia &12.0x Dia
Drill Type Indexable Drill
Type Indexable Drill Single Insert
Multi Spindle Yes
