Picture of Ingersoll TN1N-40R02 Milling Cutter 45.0° 4.000 Shell1.5000 8 Flute 0.33 Max DOC 2.375 OAL

Ingersoll TN1N-40R02 Milling Cutter 45.0° 4.000 Shell1.5000 8 Flute 0.33 Max DOC 2.375 OAL

Part Number: ING3025684 ISO: TN1N-40R02 ANSI:TN1N-40R02
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009025
Vendor: Sussex Tool and Supply
$1,166.67

Description

INGERSOLL 3025684 Parallelogram 45.0°, Face Mill SHELL1.5000 Negative 4.0000 101.60MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Non Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style AN
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Negative
Dimensions & Sizing
Overall Length 2.3750 60.33MM
Flutes/Inserts 8
Tool Dia 4.0000 101.60MM
Insert Size Ic 16
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 4.0000 101.60MM
Depth Of Cut Max 0.3300
Cut Dia Max 4.7500 120.65MM
Materials & Finish
Tool Material Steel
