Picture of Ingersoll TN1N-30R01 Milling Cutter 45.0° 3.000 Shell1.0000 5 Flute 0.33 Max DOC 1.750 OAL

Ingersoll TN1N-30R01 Milling Cutter 45.0° 3.000 Shell1.0000 5 Flute 0.33 Max DOC 1.750 OAL

Part Number: ING3025681 ISO: TN1N-30R01 ANSI:TN1N-30R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009022
Vendor: Sussex Tool and Supply
$895.07

Description

INGERSOLL 3025681 Parallelogram 45.0°, Face Mill SHELL1.0000 Negative 3.0000 76.20MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Non Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style AN
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Negative
Dimensions & Sizing
Overall Length 1.7500 44.45MM
Flutes/Inserts 5
Tool Dia 3.0000 76.20MM
Insert Size Ic 16
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 3.0000 76.20MM
Depth Of Cut Max 0.3300
Cut Dia Max 3.7500 95.25MM
Materials & Finish
Tool Material Steel
