Picture of Ingersoll TJ5N-80R01 Milling Cutter 90.0° 8.000 Shell2.5000 14 Flute 0.59 Max DOC 2.480 OAL

Ingersoll TJ5N-80R01 Milling Cutter 90.0° 8.000 Shell2.5000 14 Flute 0.59 Max DOC 2.480 OAL

Part Number: ING3025679 ISO: TJ5N-80R01 ANSI:TJ5N-80R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009020
Vendor: Sussex Tool and Supply
$2,193.33

Description

INGERSOLL 3025679 Parallelogram 90.0°, Face Mill SHELL2.5000 Negative 8.0000 203.20MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Non Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style AN
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Negative
Dimensions & Sizing
Overall Length 2.4800 62.99MM
Shank/Pilot Dia 2.5000 63.50MM
Flutes/Inserts 14
Tool Dia 8.0000 203.20MM
Insert Size Ic 16
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 8.0000 203.20MM
Depth Of Cut Max 0.5900
Materials & Finish
Tool Material Steel
