Ingersoll 6146076 0.3543 (9.00 mm) Gold Twist Double Margin (M2) Replaceable Tip Steel
Ingersoll 6146076 0.3543 (9.00 mm) Gold Twist Double Margin (M2) Replaceable Tip Steel
Part Number: ING6146076 ISO: 6146076
Need Assistance or Service? Please call 262-251-4020
Manufacturer:
INGERSOLL
SKU:
1106939
Vendor:
Sussex Tool and Supply
$0.00
This product has a minimum quantity of 2
Qty:
Add to cart
Add to My List
Add to compare list
Email a friend
Share This:
INGERSOLL 6146076 0.3543 (9.00 mm) Gold Twist Double Margin (M2) Replaceable Tip|Steel Carbide Titanium aluminium nitride (TiAlN) or aluminium titanium nitride (AlTiN; for aluminium contents higher than 50%) is a group of metastable hard coatings consisting of nitrogen and the metallic elements aluminium and titanium. This compound as well as similar compounds(such as TiN and TiCN) are most notably used for coating machine tools such and endmills and drills to change their properties, such as increased thermal stability and/or wear resistance. Four important compositions (metal content 100 wt.%) are deposited in industrial scale by physical vapor deposition methods:
Products specifications
Attribute name
Attribute value
Shipping State
ILLINOIS
Made In USA
NO
Cutter Type
Insert
Tool Material
Carbide
Cutting Edge Mat
Carbide
Cut Rating
<48HRC Steel, Gray Iron, Ductile Iron
Coating
TiAlN
Coolant Thru
Thru Coolant
Flutes/Inserts
2
Tool Dia
0.3543 9.00MM
Type Of Tool
Drill
Included Angle
140°
Cut Dia Min
0.3543 9.00MM
Dia Deep
1.5.0x Dia, 5.0x Dia, 3.0x Dia, 8.0x Dia &12.0x Dia
Drill Type
Indexable Drill
Type Indexable Drill
Single Insert
Multi Spindle
Yes
