Picture of Ingersoll 2J1R-50R01 Milling Cutter 90.0° 5.000 Shell1.5000 13 Flute Coolant 0.47 Max DOC 2.375 OAL

Ingersoll 2J1R-50R01 Milling Cutter 90.0° 5.000 Shell1.5000 13 Flute Coolant 0.47 Max DOC 2.375 OAL

Part Number: ING2916678 ISO: 2J1R-50R01 ANSI:2J1R-50R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1008550
Vendor: Sussex Tool and Supply
$1,306.67

Description

INGERSOLL 2916678 Parallelogram 90.0°, Face Mill SHELL1.5000 Positive 5.0000 127.00MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Face Mill
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 2.3750 60.33MM
Flutes/Inserts 13
Tool Dia 5.0000 127.00MM
Insert Size Ic 13
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 5.0000 127.00MM
Depth Of Cut Max 0.4700
Max Ramp Angle 0.50°
Materials & Finish
Tool Material Steel
