Picture of Ingersoll 22Q3R045050F2R00 Milling Cutter 15.0° 1.771 Shell1.0630 4 Flute Coolant 0.354 Max DOC 1.968 OAL

Ingersoll 22Q3R045050F2R00 Milling Cutter 15.0° 1.771 Shell1.0630 4 Flute Coolant 0.354 Max DOC 1.968 OAL

Part Number: ING5884436 ISO: 22Q3R045050F2R00 ANSI:22Q3R045050F2R00
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009636
Vendor: Sussex Tool and Supply
$2,006.67

Description

INGERSOLL 5884436 Parallelogram 15.0°, Chamfer Mill, Corn Cob SHELL1.0630 Positive 1.7710 44.98MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 1.9685 50.00MM
Shank/Pilot Dia 1.0630 27.00MM
Flutes/Inserts 4
Tool Dia 1.7710 44.98MM
Insert Size Ic 13
Geometry & Angles
Cutting Edge Angle 15.0°
Performance & Capacity
Cut Dia Min 1.7720 45.01MM
Depth Of Cut Max 0.3540
Cut Dia Max 4.4290 112.50MM
Materials & Finish
Tool Material Steel
