Picture of Ingersoll 22Q3R-17020D4R01 Milling Cutter 15.0° 1.750 Cylindrical1.2500 4 Flute Coolant 0.338 Max DOC 2.000 OAL

Ingersoll 22Q3R-17020D4R01 Milling Cutter 15.0° 1.750 Cylindrical1.2500 4 Flute Coolant 0.338 Max DOC 2.000 OAL

Part Number: ING2924443 ISO: 22Q3R-17020D4R01 ANSI:22Q3R-17020D4R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1008636
Vendor: Sussex Tool and Supply
$1,260.00

Description

INGERSOLL 2924443 Parallelogram 15.0°, Chamfer Mill, Corn Cob End Mill Cylindrical 1.2500 Positive 1.7500 44.45MM - 1-3/4Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 2.0000 50.80MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 4
Tool Dia 1.7500 44.45MM - 1-3/4
Insert Size Ic 13
Geometry & Angles
Cutting Edge Angle 15.0°
Performance & Capacity
Cut Dia Min 1.7500 44.45MM - 1-3/4
Depth Of Cut Max 0.3380
Cut Dia Max 4.3050 109.35MM
Materials & Finish
Tool Material Steel
