Picture of Ingersoll 22P3R045050F2R00 Milling Cutter 30.0° 1.771 Shell1.0630 4 Flute Coolant 0.6811 Max DOC 1.968 OAL

Ingersoll 22P3R045050F2R00 Milling Cutter 30.0° 1.771 Shell1.0630 4 Flute Coolant 0.6811 Max DOC 1.968 OAL

Part Number: ING5884437 ISO: 22P3R045050F2R00 ANSI:22P3R045050F2R00
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009637
Vendor: Sussex Tool and Supply
$2,006.67

Description

INGERSOLL 5884437 Parallelogram 30.0°, Chamfer Mill, Corn Cob SHELL1.0630 Positive 1.7710 44.98MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 1.9685 50.00MM
Shank/Pilot Dia 1.0630 27.00MM
Flutes/Inserts 4
Tool Dia 1.7710 44.98MM
Insert Size Ic 13
Geometry & Angles
Cutting Edge Angle 30.0°
Performance & Capacity
Cut Dia Min 1.7720 45.01MM
Depth Of Cut Max 0.6811
Cut Dia Max 4.1500 105.41MM
Materials & Finish
Tool Material Steel
