Picture of Ingersoll 22P3R-17020D4R01 Milling Cutter 30.0° 1.750 Shell1.2500 4 Flute Coolant 0.656 Max DOC 2.000 OAL

Ingersoll 22P3R-17020D4R01 Milling Cutter 30.0° 1.750 Shell1.2500 4 Flute Coolant 0.656 Max DOC 2.000 OAL

Part Number: ING2924409 ISO: 22P3R-17020D4R01 ANSI:22P3R-17020D4R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1008635
Vendor: Sussex Tool and Supply
$1,260.00

Description

INGERSOLL 2924409 Parallelogram 30.0°, Chamfer Mill, Corn Cob SHELL1.2500 Positive 1.7500 44.45MM - 1-3/4Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Coolant Thru Thru Coolant
Type Of Tool Face / Shell Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 2.0000 50.80MM
Shank/Pilot Dia 1.2500 31.75MM - 1-1/4
Flutes/Inserts 4
Tool Dia 1.7500 44.45MM - 1-3/4
Insert Size Ic 13
Geometry & Angles
Cutting Edge Angle 30.0°
Performance & Capacity
Cut Dia Min 1.7500 44.45MM - 1-3/4
Depth Of Cut Max 0.6560
Cut Dia Max 4.0340 102.46MM
Materials & Finish
Tool Material Steel
