Picture of Ingersoll 22N3X-13020D3R01 Milling Cutter 45.0° 3.300 Cylindrical1.0000 3 Flute 0.95 Max DOC 2.000 OAL

Ingersoll 22N3X-13020D3R01 Milling Cutter 45.0° 3.300 Cylindrical1.0000 3 Flute 0.95 Max DOC 2.000 OAL

Part Number: ING3028732 ISO: 22N3X-13020D3R01 ANSI:22N3X-13020D3R01
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1009144
Vendor: Sussex Tool and Supply
$1,092.00

Description

INGERSOLL 3028732 Parallelogram 45.0°, Chamfer Mill, Corn Cob End Mill Cylindrical 1.0000 Positive 3.3000 83.82MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Coolant Thru Non Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Semi Finishing
Insert Style AO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 2.0000 50.80MM
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 3
Tool Dia 3.3000 83.82MM
Insert Size Ic 12
Geometry & Angles
Cutting Edge Angle 45.0°
Performance & Capacity
Cut Dia Min 1.3750 34.93MM - 1-3/8
Depth Of Cut Max 0.9500
Cut Dia Max 3.3000 83.82MM
Materials & Finish
Tool Material Steel
