Picture of Ingersoll 22M3R-17020D3R01 Milling Cutter 60.0° 1.750 Cylindrical1.0000 4 Flute Coolant 1.15 Max DOC 2.000 OAL

Ingersoll 22M3R-17020D3R01 Milling Cutter 60.0° 1.750 Cylindrical1.0000 4 Flute Coolant 1.15 Max DOC 2.000 OAL

Part Number: ING2924348 ISO: 22M3R-17020D3R01 ANSI:22M3R-17020D3R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: 1008633
Vendor: Sussex Tool and Supply
$1,200.00
INGERSOLL 2924348 Parallelogram 60.0°, Chamfer Mill, Corn Cob End Mill Cylindrical 1.0000 Positive 1.7500 44.45MM - 1-3/4Cutter Dia Steel
Products specifications
Attribute name Attribute value
Shipping State ILLINOIS
Made In USA NO
Cutter Type Chamfer Mill, Corn Cob
Tool Material Steel
Machine Side Connection Type Cylindrical
Mach Side Connection Size 1.0000 25.40MM
Overall Length 2.0000 50.80MM
Coolant Thru Thru Coolant
Shank/Pilot Dia 1.0000 25.40MM
Flutes/Inserts 4
Tool Dia 1.7500 44.45MM - 1-3/4
Type Of Tool End Mill
Insert/Tool TOOL
Insert Application Semi Finishing
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Insert Size Ic 13
Cut Dia Min 1.7500 44.45MM - 1-3/4
Depth Of Cut Max 1.1500
Cut Dia Max 3.0820 78.28MM
Cutting Edge Angle 60.0°
