Picture of Ingersoll 1KJ1D-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.275 Max DOC 4.000 OAL

Ingersoll 1KJ1D-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.275 Max DOC 4.000 OAL

Part Number: ING3031479 ISO: 1KJ1D-0702084R01 ANSI:1KJ1D-0702084R01
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$361.20
SKU: 1009423

Description

INGERSOLL 3031479 Triangle 90.0°, End Mill End Mill Weldon 0.7500 Positive 0.7250 18.42MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type End Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Finishing, Roughing, Semi Finishing
Insert Style TH
Insert Shape/Cutter Pocket Shape Triangle
Insert Type Positive
Dimensions & Sizing
Overall Length 4.0000 101.60MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 2
Tool Dia 0.7250 18.42MM
Insert Size Ic 6
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 0.7250 18.42MM
Depth Of Cut Max 0.2750
Max Ramp Angle 3.10°
Materials & Finish
Tool Material Steel
