Picture of Ingersoll 12J1X-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 4.000 OAL

Ingersoll 12J1X-0702084R01 Milling Cutter 90.0° 0.725 Weldon 0.7500 2 Flute Coolant 0.49 Max DOC 4.000 OAL

Part Number: ING3024804 ISO: 12J1X-0702084R01 ANSI:12J1X-0702084R01
Tool Cross-Reference
Looking for alternatives…
Manufacturer:
$324.80
SKU: 1008957

Description

INGERSOLL 3024804 Parallelogram 90.0°, End Mill End Mill Weldon 0.7500 Positive 0.7250 18.42MM Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State ILLINOIS
Made In USA NO
Cutter Type End Mill
Coolant Thru Thru Coolant
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style AO
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Type Positive
Dimensions & Sizing
Overall Length 4.0000 101.60MM
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Flutes/Inserts 2
Tool Dia 0.7250 18.42MM
Insert Size Ic 12
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Cut Dia Min 0.7250 18.42MM
Depth Of Cut Max 0.4900
Max Ramp Angle 7.00°
Materials & Finish
Tool Material Steel
