HTC 199-2750 DIA 3/4 SH 0.7500 LOC 0.8750 OAL4.00 End Mill Standard Flute Standard Helix Carbide TiN Double End Ball NoseBall

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HTC
SKU: HTC199-2750
Delivery date: 3-5 days
$122.00
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Material # Material#15, Material#8, Material#17, Material#3
Application Copy Milling, Side Milling, Ball Slot Milling, Profile Milling, Ball Milling
Sold by Pieces 1
Additional Key Information 1 End Mill
Additional Key Information 3 Standard Flute
Coating TiN
Shipping State Michigain
Package Size 1
Additional Key Information 2 Ball Nose
Additional Key Information 4 Standard Helix
Performance Rating General Performance
Uncategorized
Made In USA Yes
Dimensional Specifications
Dimension Description 0.750 x 0.750 x 0.875 x 4.000
Machine Side CYLINDRICAL0.7500
Tool Material Carbide
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Single/Double End Double End
Cutter Dia 0.7500 19.05MM - 3/4
Machine Side Connection Size 0.7500 19.05MM
End Of Tool Shape Ball Nose
Overall Len 4.0000 101.60MM
Helix Angle 30°
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Style Carbide Ball Finisher
Shank/Pilot Dia 0.7500 19.05MM - 3/4
Length Of Cut 0.8750 22.23MM
Flutes/Inserts 2
Length Type Standard
Cutting & Machining Properties
Cutting Edge Mat Carbide
Center Cutting Yes
Coolant Thru No
Industry-Specific Applications
Job Shop Yes
