HTC 140-3100 DIA 1 SH 1.00 LOC 1.50 OAL4.00 End Mill Standard Flute Standard Helix Carbide TiN Single End Ball NoseBall

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HTC
SKU: HTC140-3100
Delivery date: 3-5 days
$179.40
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Additional Key Information 2 Ball Nose
Package Size 1
Application Ball Milling, Ball Slot Milling, Side Milling, Copy Milling, Profile Milling
Sold by Pieces 1
Additional Key Information 1 End Mill
Additional Key Information 3 Standard Flute
Coating TiN
Material # Material#3, Material#17, Material#15, Material#8
Additional Key Information 4 Standard Helix
Performance Rating General Performance
Shipping State Michigain
Uncategorized
Made In USA Yes
Dimensional Specifications
Machine Side CYLINDRICAL1.0000
Length Of Cut 1.5000 38.10MM
End Of Tool Shape Ball Nose
Overall Len 4.0000 101.60MM
Helix Angle 30°
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Dimension Description 1.000 x 1.000 x 1.500 x 4.000
Flutes/Inserts 3
Cutter Dia 1.0000 25.40MM
Length Type Standard
Tool Material Carbide
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Inch/Metric Inch
Cutter Style Carbide Ball Finisher
Single/Double End Single End
Cutting & Machining Properties
Coolant Thru No
Cutting Edge Mat Carbide
Center Cutting Yes
Industry-Specific Applications
Job Shop Yes
