HTC 140-2140 DIA 9/64 SH 0.1875 LOC 0.5625 OAL2.00 End Mill Standard Flute Standard Helix Carbide TiN Single End Ball NoseBall

Need Assistance or Service? Please call 262-251-4020

Manufacturer: HTC
SKU: HTC140-2140
Delivery date: 3-5 days
$13.68
Ship to
*
*
Shipping Method
Name
Estimated Delivery
Price
No shipping options

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

Titanium nitride (TiN) coating is wear resistant, inert & reduces friction. Used on cutting tools punches etc improving tool life 2-10x over uncoated tools

Products specifications
Attribute name Attribute value
General Product Information
Material # Material#17, Material#8, Material#3, Material#15
Additional Key Information 2 Ball Nose
Additional Key Information 4 Standard Helix
Shipping State Michigain
Package Size 1
Additional Key Information 3 Standard Flute
Application Ball Slot Milling, Profile Milling, Side Milling, Copy Milling, Ball Milling
Coating TiN
Sold by Pieces 1
Additional Key Information 1 End Mill
Performance Rating General Performance
Uncategorized
Made In USA Yes
Dimensional Specifications
Shank/Pilot Dia 0.1875 4.76MM - 3/16
Flutes/Inserts 2
Length Type Standard
End Of Tool Shape Ball Nose
Machine Side CYLINDRICAL0.1875
Single/Double End Single End
Cut Rating <42HRC Steel, Ductile Iron, Gray Iron, Stainless Steel
Cutter Style Carbide Ball Finisher
Dimension Description 0.141 x 0.188 x 0.563 x 2.000
Cutter Dia 0.1406 3.57MM - 9/64 - #28
Helix Angle 30°
Length Of Cut 0.5625 14.29MM
Tool Material Carbide
Machine Side Connection Type Cylindrical
Inch/Metric Inch
Machine Side Connection Size 0.1875 4.76MM
Overall Len 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru No
Center Cutting Yes
Cutting Edge Mat Carbide
Industry-Specific Applications
Job Shop Yes
