Picture of Dijet SEC-2150-3.5-S125 Milling Cutter 90.0°, Drill Mill 1.500 Cutter Diameter Weldon 1.500 Shank 7.500 OAL 8 Flute

Dijet SEC-2150-3.5-S125 Milling Cutter 90.0°, Drill Mill 1.500 Cutter Diameter Weldon 1.500 Shank 7.500 OAL 8 Flute

Part Number: DIJSEC-2150-3.5-S125 1.500 x 1.500 x 3.500 x 7.500 ISO: SEC-2150-3.5-S125 ANSI:SEC-2150-3.5-S125
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1004183
Vendor: Sussex Tool and Supply
Call (262) 251-4020 for pricing

Description

DIJET SEC-2150-3.5-S125 90.0°, Drill Mill Drill Mill Weldon 1.5000 Positive 1.5000 38.10MM - 1-1/2Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State MICHIGAN
Made In USA NO
Cutter Type Drill Mill
Type Of Tool Drill Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style ZD, ZP
Insert Shape/Cutter Pocket Shape Other
Insert Type Positive
Insert Screw DSW-4510H
Dimensions & Sizing
Overall Length 7.5000 190.50MM
Shank/Pilot Dia 1.5000 38.10MM - 1-1/2
Flutes/Inserts 8
Tool Dia 1.5000 38.10MM - 1-1/2
Length Of Cut 3.5000 88.90MM
Insert Size Ic 19
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Depth Of Cut Max 3.5000
Materials & Finish
Tool Material Steel
