Picture of Dijet SEC-2062-0.5-S062 Milling Cutter 90.0°, Drill Mill 0.625 Cutter Diameter Weldon 0.625 Shank 5.000 OAL 4 Flute

Dijet SEC-2062-0.5-S062 Milling Cutter 90.0°, Drill Mill 0.625 Cutter Diameter Weldon 0.625 Shank 5.000 OAL 4 Flute

Part Number: DIJSEC-2062-0.5-S062 0.625 x 0.625 x 0.500 x 5.000 ISO: SEC-2062-0.5-S062 ANSI:SEC-2062-0.5-S062
Looking for alternatives…

Need Assistance or Service? Please call 262-251-4020

Manufacturer:
SKU: 1004167
Vendor: Sussex Tool and Supply
Call (262) 251-4020 for pricing

Description

DIJET SEC-2062-0.5-S062 90.0°, Drill Mill End Mill Weldon 0.6250 Positive 0.6250 15.88MM - 5/8Cutter Dia Steel
Products specifications
Attribute name Attribute value
General Information
Shipping State MICHIGAN
Made In USA NO
Cutter Type Drill Mill
Type Of Tool End Mill
Insert/Tool TOOL
Cut Type Roughing, Semi Finishing
Insert Style ZD, ZP
Insert Shape/Cutter Pocket Shape Other
Insert Type Positive
Insert Screw TSW-2250
Dimensions & Sizing
Overall Length 5.0000 127.00MM
Shank/Pilot Dia 0.6250 15.88MM - 5/8
Flutes/Inserts 4
Tool Dia 0.6250 15.88MM - 5/8
Length Of Cut 0.5000 12.70MM
Insert Size Ic 8
Geometry & Angles
Cutting Edge Angle 90.0°
Performance & Capacity
Depth Of Cut Max 0.5000
Materials & Finish
Tool Material Steel
