Picture of Dijet DBD-187-031 JC5030 Milling Insert Back Draft 0.310 Corner Radius Carbide PVD Special

Dijet DBD-187-031 JC5030 Milling Insert Back Draft 0.310 Corner Radius Carbide PVD Special

Part Number: DIJDBD-187-031 JC5030

Need Assistance or Service? Please call 262-251-4020

Manufacturer: DIJET
SKU: 1004038
Vendor: Sussex Tool and Supply
$0.00
This product has a minimum quantity of 10

DIJET milling insert with back draft 0.310 corner radius carbide PVD coating grade JC5030. Made in Usa: No. Shipping State: MICHIGAN. Tool Material: Carbide. Grade: JC5030.

Key Details

Materials & Finish

  • Coating: PVD Special
  • Tool Material: Carbide
  • Grade: JC5030

Grades & Coatings

  • Alternate Description: DIJET DBD-187-031 JC5030 Flat Blade Insert Positive PVD Special DBD-187-031 JC5030 DBD-187-031 JC5030

Other Details

  • Brand: DIJET
  • Shipping State: MICHIGAN
  • Made In Usa: No

Technical Overview

What It Does

Milling insert performs back draft function. Operates with 0.310 corner radius. Used in cutting operations with carbide blade.

Composition

Carbide tool material. PVD Special coating. Grade JC5030.

Typical Uses

Milling operations. Cutting with flat blade insert. Back draft applications in machining.

Products specifications
Attribute name Attribute value
Shipping State MICHIGAN
Cutter Type Insert
Made In USA No
Cutting Edge Definition Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.
Cutting Edge Material Carbide
Tool Material Carbide
Coating PVD Special
Insert Or Tool Insert
Insert Application Finishing, Semi Finishing
Corner Radius 0.3100 7.87MM
Insert Style DB
Insert Shape Or Cutter Pocket Shape Flat Blade
Insert Type Positive
Insert Size (IC) 187
Grade JC5030
Insert Fits Back Draft
