Picture of AB Tools CHA150-2 Triangle 150.0°, Chamfer Mill End Mill Weldon 0.7500 Positive

AB Tools CHA150-2 Triangle 150.0°, Chamfer Mill End Mill Weldon 0.7500 Positive

Part Number: ABTCHA150-2

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AB TOOLS
SKU: 1000090
Vendor: Sussex Tool and Supply
$325.00

AB TOOLS CHA150-2 Triangle 150.0° Chamfer Mill End Mill Weldon 0.7500 Positive. Made in USA, shipping state California. Toolpost connection type Weldon, machine side WELDON0.7500. Tool material steel.

Key Details

Materials & Finish

  • Tool Material: Steel

Thread & Fittings

  • Machine Side (Toolpost) Connection Type: Weldon
  • Machine Side (Toolpost): WELDON0.7500

Grades & Coatings

  • Alternate Description: AB TOOLS CHA150-2 Triangle 150.0°, Chamfer Mill End Mill Weldon 0.7500 Positive CHA150-2 CHA150-2

Other Details

  • Brand: AB TOOLS
  • Shipping State: CALIFORNIA
  • Made In Usa: Yes
  • Type Of Tool: End Mill

Technical Overview

What It Does

Chamfers material with 150.0° angle. Performs cutting on machine with Weldon connection. Used for precise edge finishing on metal parts.

Composition

Steel tool material. Weldon 0.7500 connection. AB TOOLS brand.

Typical Uses

Chamfering on metal workpieces. Cutting in machine with Weldon post. End mill operation in milling machines.

Products specifications
Attribute name Attribute value
Shipping State CALIFORNIA
Cutter Type Chamfer Mill
Made In USA YES
Tool Material Steel
Machine Side (Toolpost) WELDON0.7500
Machine Side (Toolpost) Connection Type Weldon
Overall Length 3.5000 88.90MM
Shank Or Pilot Diameter 0.7500 19.05MM - 3/4
Mach Side Connection Size 0.7500 19.05MM - 3/4
Flutes Or Inserts 2
Type of Tool End Mill
Length Of Cut 0.1400 3.56MM
Insert Or Tool Tool
Insert Application General Purpose
Insert Style TP
Insert Shape Or Cutter Pocket Shape Triangle
Insert Type Positive
Insert Size (IC) 16 "32"
Cut Diameter Min 0.4700 11.94MM
Depth Of Cut Max 0.5200
Cut Diameter Max 1.5600 39.62MM
Cutting Edge Angle 150.0°
Clamp Screw 10-32 SHC
Clamp Or Wedge CL2
Seat Or Nest SM-41
