Picture of AB Tools CHA130-3 Triangle 130.0°, Chamfer Mill End Mill Weldon 1.0000 Negative

AB Tools CHA130-3 Triangle 130.0°, Chamfer Mill End Mill Weldon 1.0000 Negative

Part Number: ABTCHA130-3

Need Assistance or Service? Please call 262-251-4020

Manufacturer: AB TOOLS
SKU: 1000100
Vendor: Sussex Tool and Supply
$475.00

AB TOOLS CHA130-3 Triangle 130.0° Chamfer Mill End Mill Weldon 1.0000 Negative. Made in USA, shipping state California. Toolpost connection Weldon, material steel. Type of tool: End Mill.

Key Details

Materials & Finish

  • Tool Material: Steel

Thread & Fittings

  • Machine Side (Toolpost) Connection Type: Weldon
  • Machine Side (Toolpost): WELDON1.0000

Grades & Coatings

  • Alternate Description: AB TOOLS CHA130-3 Triangle 130.0°, Chamfer Mill End Mill Weldon 1.0000 Negative CHA130-3 CHA130-3

Other Details

  • Brand: AB TOOLS
  • Shipping State: CALIFORNIA
  • Made In Usa: Yes
  • Type Of Tool: End Mill

Technical Overview

What It Does

Chamfers edges with 130.0° angle. Mill end mill cuts material. Weldon 1.0000 negative profile for precise fit.

Composition

Steel tool material. Weldon 1.0000 connection. CHA130-3 triangle shape.

Typical Uses

Used in milling machines. Fits Weldon toolpost. Chamfers metal edges.

Products specifications
Attribute name Attribute value
Shipping State CALIFORNIA
Cutter Type Chamfer Mill
Made In USA YES
Tool Material Steel
Machine Side (Toolpost) WELDON1.0000
Machine Side (Toolpost) Connection Type Weldon
Overall Length 3.8000 96.52MM
Shank Or Pilot Diameter 1.0000 25.40MM
Mach Side Connection Size 1.0000 25.40MM
Flutes Or Inserts 3
Type of Tool End Mill
Length Of Cut 0.3200 8.13MM
Insert Or Tool Tool
Insert Application General Purpose
Insert Style TN
Insert Shape Or Cutter Pocket Shape Triangle
Insert Type Negative
Insert Size (IC) 43
Cut Diameter Min 0.7700 19.56MM
Depth Of Cut Max 0.6700
Cut Diameter Max 2.1600 54.86MM
Cutting Edge Angle 130.0°
Clamp Screw 10-32 SHC
Clamp Or Wedge CL5
Seat Or Nest SM-26
